Genie Long-Range Photoelectric Reflective Sensor with Reflector (NEMA 4, 40 ft) - 113468.0001.S
Details
Genie Long-Range Photoelectric Reflective Sensor with Reflector (NEMA 4, 40 ft) - 113468.0001.S
This Genie Long-Range Photoelectric Reflective Sensor provides consistent detection for gate opener systems using a 3" reflector and hood to reduce false triggers. The rectangular plastic body with terminal block connection makes wiring simple. It offers selectable Light-ON/Dark-ON operation and a relay output for easy integration with gate controls. Its 40-foot range and NEMA-rated housing make it ideal for outdoor and industrial installations.
Features:
- Easy to wire terminal strip
- Plug-In replaceable outputs
- Timer modules available
- Long-Range Detection
Specifications:
- Retroreflective detection
- 40ft Sensing Distance
- Terminal Block Connection
- NEMA 4 Platic Housing
- Light-ON/Dark-ON (Switch Selectable)
- DPDT 10 A Relay Output
- Input Voltage: 42 to 240 VAC, 24 to 240 VDC
| SKU | 113468-0001-S |
|---|---|
| Condition | New |
| Manufacturer | Genie |
Input Voltage
Need to know the difference between voltages? Check out our guide!
Learn More
|
12 AC, 12 DC, 24 AC, 24 DC, 36 AC, 36 DC, 48 AC, 48 DC, 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase), 240 AC (60 Hz, 3 Phase) |
